Technical specifications:

MODEL: PVS-22pro(Thermal night vision goggles)

structure mode: goggle

Structural mode: Arbitrary turn it over

Battery type: Lithium battery (cr123x1) / cr23x4 external battery box

Power supply: 1.2-1.6/2.5-4.2V

Installation: Head mounted(standard FST helmet interface)

control mode: ON/IR/AUTO

Over power consumption： <0.1W /1.2W

Battery capacity： 300-3200maH

Battery life： 30-100H

magnification： 1X

FOV( °)： >50°

Parallelism of optical axis： <0.5°

IIT：Gen2+/3

Lens system： F1.18 22.5mm

MTF： 120LP/mm

Optical distortion： 1% Max

Relative Illumination：>75%

coating： Multilayer broadband coating

Range of focus： 250mm-∞

Focus mode：manual focus facility

Distance of pupil： 30-35mm

Eyepiece aperture： 9mm

Range of visibility： 0 (+ / - 5 optional)

Type of display： OLED

display resolution： 1280x720

Display image ratio： 80%

Thermal image wavelength：8-12uM

Thermal image resolution： 640x512

Fusion mode： Optical fusion

IR： 850nm 20mW

Operating temperature：-40--+55℃

Relative temperature：5%-95%

Environment rating： IP65/IP67

dimensions: 80x132x81

weight: 430G
